The Keypad is made of zinc alloy to effectively prevent vandalism and suitable for occasions that
needs high security levels such as banks and prisons
· Vandalproof design,capacitive mechanical keypad with blue backlight
· Support EM/125KHz card（Mifare/13.56MHz ISO14443A optional)
· When working with controller,it provides unlock modes including card-swiping,pressing keypad or card-swiping+password
· Vandalproof design,capacitive mechanical keypad with blue backlight
· Support EM/125KHz card（Mifare/13.56MHz ISO14443A optional)
· When working with controller,it provides unlock modes including card-swiping,pressing keypad or card-swiping+password
· Wiegand 26/34 output, other formats need to be customized, ranging from Wiegand 26 to 42.
· Provides wiegand(default) and RS232/RS485 different communication interfaces to connect with controllers for different site requirements
· Provides RS-485 communication interface version(DX-RM2EW-RS485) for long distance installation
· Additional functions: Dustproof, LED and buzzer controlled via external controller(optional).
Specifications:
· Provides wiegand(default) and RS232/RS485 different communication interfaces to connect with controllers for different site requirements
· Provides RS-485 communication interface version(DX-RM2EW-RS485) for long distance installation
· Additional functions: Dustproof, LED and buzzer controlled via external controller(optional).
Specifications:
|
Model No.
|
DX-RM2EW
|
DX-RM2EW-RS485
|
DX-RM2EW-RS232
|
|
Read Format
|
EM/125KHz( Mifare/13.56MHz optional)
|
||
|
Read Range
|
3-8CM(Max.)
|
3-8CM(Max.)
|
3-8CM(Max.)
|
|
Comm.Interface
|
Wiegand 26(default)/34 output |
RS485 |
RS232
|
| Vandal-resistant Case | Yes | ||
|
Keypad
|
/
|
||
|
Verification Type |
Card
|
||
|
Comm.Baudrate
|
None
|
9,600 bps-N-8-1 |
9,600 bps-N-8-1 |
|
LED Indicator
|
Green / Red Bi-color LED x 1 (Status / Power)
|
||
|
Beep Tone
|
Buzzer
|
||
|
Ingress Protection Rate |
IP67
|
||
|
Working Voltage |
12V DC ±10％
|
||
|
Current Consumption |
60mA (max)
|
||
|
Operating Temperature |
-30°C - 75°C
|
||
|
Operating Humidity |
20% ~ 80%(Non-condensing) |
||
|
Unit Weight
|
300g
|
||
|
Dimension(WxHxD)
|
84*57*22mm
|
||
