Product Parameter
|
Parameter Description
|
|
Input Voltage
|
12DC+10%
|
|
Current
|
Start:450mA Standby:120mA
|
|
Timer
|
N/A
|
|
Signal Output
|
NC/COM
|
|
Decorative Plate
|
200L*28W*35H(mm)
|
|
Strike(Stainless steel)
|
90L*25W*3H(mm)
|
|
Bolt
|
16mm DIA,Stainless steel 16mm throw
|
|
Feature
|
Fail Safe
|
|
Surface temp
|
Low temperature
|
|
Induction Distance
|
8mm
|
|
Operating Temp
|
40 ℃~+50 ℃
|
|
Suitable Humidity
|
0~95%(non-condensing)
|
|
Suitable For
|
Glass door,metal door,wooden door
|
|
Weight
|
0.65kg
|
|
Packing details
|
30pcs/ctn, 40.5*27.9*31cm
|
|
Wiring Guide
|
|
|
Red
|
+DC 12V
|
|
Black
|
-GND
|
|
Yellow
|
Button switch+(Push)
|
|
White
|
Signal Output
|
|
Brown
|
COM (with signal)
|
|
Blue
|
No (with signal)
|
|
Green
|
NC (with signal
|
