Working Mode
|
Standalone(Offline)
|
|
CPU
|
200MHZ tailor-made CPU
|
|
Recognition Mode
|
Fingerprint or ID/EM Card(Mifare card is optional,if u need,plz contact us freely)
|
|
Fingerprint Capacity
|
1000
|
|
RF ID card capacity
|
1000 (125khz)
|
|
Read distance
|
3~10cm
|
|
Fingerprint Collector
|
1.8*1.8mm 500dpi optical sensor
|
|
Response Time
|
<1s (full of 3000)
|
|
Sensor Mode
|
Uncoated Optical Sensor, Scratch and impact resistant
|
|
Allowable Finger Rotation
|
180
|
|
Activation
|
Manual or Induction
|
|
Idle Mode
|
Yes
|
|
Bell
|
Bell output
|
|
LED (Green/Red) Display
|
Yes
|
|
Enrollment Data Transfer
|
MINI SD Card(Via MINI SD card, it can send enrollment data to other F10EM)
|
|
Access Control
|
Relay NO/NC, Wiegand26 out
|
|
Alarm method
|
Dismantlement
|
|
FAR (False Acceptance Rate)
|
Less than 0.0001%
|
|
FRR (False Rejection Rate)
|
Less than 0.01%
|
|
Matching Mode
|
1: N
|
|
Working Voltage
|
DC 12V/ 3A
|
|
Working consumption
|
≤60mA(Static electricity);≤400mA when not running electric strike lock
|
|
Operating Temperature
|
0℃- 45℃
|
|
Operating Humidity
|
20%-80%
|
|
Dimension
|
155* 66*28mm(L*W*H)
|
|
Weight
|
0.22kgs
|
|
package includes
|
Device *1, Underlay *1,connecting 8 pin wire *2, installation screw bag *1,manual*1
|
